| PLOTTER CUTTING |
|
|
Our plotter is cutting plotter SC 1000, produced by MUTOH.
Technical data:
- cutting speed 1410 mm/s,
- acceleration 4 G,
- regulated blade pressure 20-500 g,
- automatic pulling out cut works with base paper
- vector providing optimalizing cutting speed on bows
- automatic pushing of a foil, copying to100 copies,
- positioning,
- roll system, base (option for SC-650), 3 blades, 2 markers
SC series plotters can cut glue foils, foils for sanding and draw
on paper or cut with the dashed line any material. Precise system
of servicing media warrants safe work even with very long materials.
|
:
|
|
|
MODEL
|
SC-650
|
SC-1000
|
SC-1300
|
|
Max. foil width (mm)
|
750 (roll)
850 (sheet)
|
1100 (roll)
1250 (sheet)
|
1320 (roll)
1420 (sheet)
|
|
Max. cutting width
|
630 mm
|
1030 mm
|
1200 mm
|
|
Gwarantowana powtarzalność
|
630mm x 12m
|
1300mm x 12m
|
1200mm x 12m
|
|
Max. cutting length
|
50 m
|
|
Max. foil thickness
|
1,2 mm
|
|
foil push system
|
tightening rolls
|
|
Cutting head
|
trailed
|
|
Mechanic dimension
|
0,005 mm
|
|
Precision
|
0,15 %
|
|
Repetition
|
0,25 mm/m
|
|
Number of tightening rolls
|
2
|
3
|
|
Blades
|
30o/45o/60o
|
|
Speed (diagonal)
|
140 - 1400 mm/s
|
|
Acceleration (axis)
|
4 G
|
|
Vertical moves of a head
|
40 /sec
|
|
Blade pressure
|
20 - 500 g
|
|
Interface
|
RS-232, centronics
|
|
RAM (optonal)
|
1 Mb (4 Mb)
|
|
Base
|
standard
|
|
Blade cutting works with base paper
|
standard
|
|
Roll system for serving a foil
|
standard
|
|
Communication languages
|
MH-GL/2 (according with HP-GL/2)
|
|
Dot configuration(0,0)
|
standard
|
|
Offset adaptation
|
half-automatic
|
|
Advanced functions
|
vector providing, smoothing bows and corners
|
|
Outline cutting
|
standard
|
|
Copying to 100 copies
|
standard
|
|
|
